Manufacture of FEIHU Yarn Winding Yarn Spinning Machine Yarn Winding Machine Wire Winding Machine Manufacturer

1 Set
MOQ
Manufacture of FEIHU Yarn Winding Yarn Spinning Machine Yarn Winding Machine Wire Winding Machine Manufacturer
Features Gallery Product Description Request A Quote
Features
Specifications
Applicable Industries: Textile
Condition: New
Application: Making Yarn
Type: Winder Machine
Production Capacity: HIGH SPEED
Spinning Method: Rotor Spinning
Automatic: Yes
Dimension(L*W*H): 1454*690*1700mm
Weight: 205kg
Power: 550kw
Warranty: 1 Year
After-sales Service Provided: Free Spare Parts, Video Technical Support, Online Support, Engineers Available To Service Machinery Overseas
Certification: ISO
Product Name: FEIHU Yarn Spinning Machine Yarn Winding Machine
Material: Steel
Color: White
For Material: Pp Pe Cotton Polyester Nylon
MODEL: Yarn Size
COLOR OF YARN: Color Pp Yarn
Number Of Spindle: 24 Spindles
Usage: Winding
Basic Infomation
Certification: ISO
Model Number: Yarn Size
Payment & Shipping Terms
Packaging Details: Export wooden case
Supply Ability: 10 Set/Sets per Day
Product Description

FEIHU FHTDTK-A NC YARN REWINDING MACHINE is our innovative design of electromechanical integration equipment. which combined the current trend of molding winding yarn. Especially suitable for elastic nylon yarn winding. It features is :fast in lane; good forming; even tension; stability of elastic stretch yarn., It is the best equipment of yarn winder machine . we took most advanced technology such as:individual motor for each spindle, automatic stop of yarn break, dead line control, slow start(startup time is adjustable), adjustable of speed of cross yarn, electric over-feed device, Single-spindle oil device, Anti-stacked device, Closing edge device .keep even in External elastic yarn, so as to achieve one time form and double the increase production efficiency . It can reduce the technical requirements of the operator as well as facilitate employment.

Product name

FHTDTK-A hank to cone winding machine

Number of spindles

24(6 spindles/group)

Spindle gauge

360 mm

Layout

Single sided, single layer

Power Supply

220V/380V

Spindle power

120w/spindle

Winding speed

500m/min(Speed adjustable)

Max. yarn diameter

≤220mm

Friction roller specification

Flat bobbin Φ 80mm×220mm
or cone Φ 80mm×220mm taper 3.5°

(Optional)

Driving

Individual

Electronic Anti-Stack

Inverter control

Dimensions

L 2200 x W 820 x H 1100 mm ( 6 spindles)

Weight

205kg/group

Productivity

10kg/spindle/24h

Operation

48 spindles/a worker
